Counter Type Evaporators

The HER range of countertype evaporators has been designed for use in refrigerated cabinets and display caseslow for the preservation of fresh products.
efficient with special profile aluminum fins and ø9.52 mm internally grooved tubes, with a reduced internal volume to reduce the necessary refrigerant charge, meeting the needs of the different international regulations for the reduction of gases with high greenhouse effect. They are supplied clean and tested under a pressure of 30 bar.



•Capacity: 0.35-1.05kw
•Fin Spacing:4.5mm
**多种制冷剂产品可选,多种配置可选

EC Fans available

Golden Fin available

Product Line

The HER Series evaporators are space-saving air coolers designed for refrigerated display counters and refrigerators.The efficient heat exchanger design ensures optimal airflow within the cooling cabinet, effectively addressing challenges posed by high ambient temperatures and frequent door openings for cooling equipment.Maintains temperatures in locations such as counters and display cabinets at optimal levels even under extreme conditions.

•White powder-coated aluminium casing with high resistance to corrosion and impacts.
•In models with electric defrost, stainless steel electric heaters covered by aluminum tubes are used, located in the finned package to avoid steam problems and make easy replacement.
•The electrical parts are connected to an earth terminal, inside a connection box with access holes equipped with cable glands with IP 65 protection.
•For performance at work points other than those in this catalog, use the “Unit Selector Hybrid HISPANIA” software.
