Hispania

Industrial Cubic Evaporators

The HEB range of industrial cubic evaporators has been designed for use in big cold rooms for the preservation of fresh and frozen products.
The exchange coils used in the HEB range are built with a geometry of recognized high efficiency, with special profile aluminum fins and ø15 mm high quality copper tubes, with high heat transfer coefficient. They are supplied clean and tested under a pressure of 30 bar.

•Capacity: 3.72-131.52kw
•Fin Spacing：4.5mm-7mm-10mm-12mm

**Multiple refrigerant options available ，Multiple configurations available

EC fan available

Optional Stainless Steel Pipe Products

Optional stainless steel housing products

Hot gas defrosting method is available.

Water defrosting method is available

Thermal protector for defrosting electrical heaters available

Golden Fin available

Double insulated drip tray available

Streamers: Airk-guiding device for increased airthrow available

Product Line

•White powder-coated aluminium casing with high resistance to corrosion and impacts.
•In models with electric defrost, stainless steel electric heaters covered by aluminum tubes are used, located in the finned package to avoid steam problems and make easy replacement.
•The electrical parts are connected to an earth terminal, inside a connection box with access holes equipped with cable glands with IP 65 protection.
•For performance at work points other than those in this catalog, use the “Unit Selector Hybrid HISPANIA” software.
